Dry Powder Electromagnetic Separator Increases Purity Of Lithium Hydroxide Materials By 19%

The fully automatic electromagnetic dry powder magnetic separator increases the purity of lithium hydroxide materials by 19%

The separation principle of lithium hydroxide materials by the fully automatic electromagnetic dry powder magnetic separator
The separation principle of lithium hydroxide materials by the fully automatic electromagnetic dry powder magnetic separator mainly utilizes electromagnetic induction to generate a magnetic field, thereby adsorbing and separating magnetic impurities. When lithium hydroxide powder passes through a magnetized medium, the magnetic impurities in it (such as mixed iron, cobalt, nickel and other metals and their compounds) will be captured by the magnetic force. However, lithium hydroxide itself is a non-magnetic or weakly magnetic substance, thus achieving the initial separation of magnetic and non-magnetic substances and obtaining initially purified lithium hydroxide products. When the adsorption capacity of the magnetic medium reaches saturation, the lower end's material distribution valve automatically turns towards the magnetic material discharge port. The electromagnetic coil is de-energized to demagnetize the medium. Meanwhile, the vibration motor increases the amplitude, causing the magnetic substances adsorbed on the medium to detach from the medium and be discharged from the discharge port, completing a cycle of iron removal. Through this continuous cycle of work, the magnetic impurities in lithium hydroxide materials can be continuously separated to ensure the purity of the product.

Why is a fully automatic electromagnetic dry powder iron remover used for the purification of lithium hydroxide materials
The JC fully automatic electromagnetic dry powder magnetic separator features high background field strength, excellent demagnetization effect, low coil temperature rise and high reliability. The special material medium network with different structures can quickly adsorb iron filings, iron powder and other impurities, ensuring the purity of the materials.
After a certain lithium hydroxide material manufacturer in China adopted the JC fully automatic electromagnetic dry powder iron remover, the purity of the lithium hydroxide product increased by 23%, achieving a purification effect of PPB-level iron content. Moreover, the equipment operates stably with low maintenance costs. Each year, it can save the manufacturer about 500,000 yuan in product losses and additional processing expenses caused by excessive impurities. It received high praise from customers for the product.

Improvement and Benifit

Efficient separation work: Over 20 Chinese lithium battery cathode material enterprises have adopted JC's dry magnetic separator. We collaborate with user enterprises to continuously optimize the inclination Angle of the feed flap valve based on different raw materials, optimize the discharge port, precisely control the material flow rate, and strive to enhance the separation capacity while ensuring the purity of the output.

The service life of the equipment is longer: The connection of the magnetic coil designed by JC adopts a special design and material, which greatly improves the reliability of the use of this core component, the electromagnetic coil. Moreover, it adopts a constant current design and current control mode, with very little change in the magnetic field. It operates more smoothly and has an extremely low failure rate, earning the trust and praise of over 50 customers worldwide. Therefore, JC offers a standard 12-month warranty period for dry magnetic separators.
